| Supported Operating Systems |
| Operating system |
Windows 7 Professional 64 (available through downgrade rights from Windows 10 Pro) |
| Operating system note |
This system is preinstalled with Windows 7 Professional software and also comes with a license and media for Windows 10 Pro software. You may only use one version of the Windows software at a time. Switching between versions will require you to uninstall one version and install the other version. You must back up all data (files, photos, etc.) before uninstalling and installing operating systems to avoid loss of your data. |
| Processor |
| Chipset |
Intel® Q170 |
| Processor family |
Intel® Core™ i5 processor |
| Processor |
Intel® Core™ i5-6500 with Intel HD Graphics 530 (3.2 GHz, up to 3.6 GHz with Intel Turbo Boost, 6 MB cache, 4 cores) |
| Memory |
| Memory |
4 GB DDR4-2133 SDRAM (1 x 4 GB) |
| Memory Slots |
4 DIMM |
| Drives |
| Internal Storage |
500 GB 7200 rpm SATA |
| Optical drive |
Slim SATA SuperMulti DVD-RW |
| External drive bays |
One 13,3 cm (5.25")
One slim ODD
1 SD 4 reader (optional) |
| Internal drive bays |
Two 8,9 cm (3.5")
One 6,35 cm (2.5’’) |
| Graphic Subsystem |
| Graphics |
Intel® HD Graphics 530 |
| Graphics |
Integrated |
| Multimedia and Input Devices |
| Audio |
DTS Studio Sound™ audio management technology, HD audio with Realtek ALC221 codec, microphone and headphone front ports (3.5 mm), line-out and line-in rear ports (3.5 mm), multi-streaming capable, internal speaker (standard) |
| Multimedia and Input Devices |
| Keyboard |
HP USB Business Slim Keyboard |
| Pointing device |
HP USB Mouse |
| Connectivity and Communications |
| Network interface |
Intel® I219LM Gigabit Network Connection LOM |
| Ports |
2 USB 3.0
2 USB 2.0 (1 fast charging)
1 audio line in
1 audio line out |
| Expansion slots |
1 PCIe x16
1 PCIe x4 (x16)
2 PCIe x1 |
| Network interface type |
LAN |
| I/O Port location |
Front |
| Ports |
6 USB 3.0
1 serial
1 serial (optional)
1 parallel (optional)
2 PS/2 (keyboard and mouse)
1 VGA
2 DisplayPort
1 audio line in
1 audio line out
1 RJ-45 |
| I/O Port location |
Back |
| Battery and Power |
| Power |
280 W, up to 92% efficient, active PFC
400 W, up to 92% efficient, active PFC |
| Weights |
| Weight |
Starting at 9.43 kg |
| System Components |
| Form factor |
Microtower |
| Security Management |
| Security management |
HP BIOSphere with Sure Start
Trusted Platform Module (TPM) 1.2/2.0 (Common Criteria EAL4+ certified)
SATA port disablement (via BIOS)
DriveLock and Automatic DriveLock
RAID (available as a configurable option)
Serial, parallel, USB enable/disable (via BIOS)
Optional USB port disable at factory (user configurable via BIOS)
Removable media write/boot control
Power-on password (via BIOS)
Setup password (via BIOS)
HP Solenoid Hood Lock/Sensor
Support for chassis padlocks and cable lock devices |
| Security management footnote number |
[13,14] |
| Software and Applications |
| Software |
HP business PCs are shipped with a variety of software titles including: HP Drive Encryption (FIPS 140-2), HP Client Security, HP Security Manager, Microsoft Security Essentials, CyberLink Power DVD BD, Native Miracast Support, HP ePrint Driver, HP Recovery Manager, Foxit PhantomPDF Express. Please refer to this product's quick spec document for a full list of preinstalled software. |
| Management features |
Intel® vPro™ |
| Software footnote number |
[10,11,12] |
| Dimensions |
| Dimensions (W x D x H) |
170 x 425.4 x 389 mm |
| Warranty |
| Warranty |
3-year limited warranty including 3 years of parts, labour, and next-business-day onsite service. Terms and conditions vary by country. Certain restrictions and exclusions apply. |
