Nimble Storage Secondary Flash Arrays

Thông số kỹ thuật

Capacity

• HPE Nimble Storage SF-Series Secondary Flash Arrays (capacity per array, with expansion): Starting at 21 TB Raw

• 16 TB Useable

• 128 TB Effective, up to 210 TB Raw

• up to 169 TB Usable

• up to 3 PB Effective (Assumes typical 3x to up to 18x savings, based on Backup retention policy, on a Veeam target)

• Starting configuration based on HPE Nimble Storage SF100 Secondary Flash Array.

Drive description

• Up to (21) LFF MDL SAS HDDs

• 1/2/4/6/10TB drive capacities supported, depending on model. (3 or 6) SFF SSD

• Depending on configuration. 480/960/1920/3840GB SSD Cache capacities supported, depending on model.

Enclosures

• (2)

• Maximum Expansion Shelves supported.

Maximum drives per enclosure

• (21) HDDs and Flash Cache per base array or SF Series Expansion Shelf.

Host interface

• 1 GbE/10GbE iSCSI (4) Ports and

• 1 GbE/10GbE iSCSI (4) Ports or

• 1 GbE/10GbE iSCSI (4) Ports and

• 10 GbE iSCSI (4) Ports or

• 1 GbE/10GbE iSCSI (4) Ports and

• 16 Gb/8 Gb Fibre Channel (4)

• Depending on configuration.

Storage controller

• 2

Availability features

• Triple+ Parity RAID for data protection Redundant storage controllers Redundant power supplies and fans

Compatible operating systems

• Microsoft Windows Server VMware ESXi SUSE Linux Enterprise Server (SLES) Red Hat Enterprise Linux (RHEL)

• Ubuntu Server Edition LTS

• Oracle Linux

• Citrix XenServer

• Oracle Solaris IBM AIX For the latest information on supported operating systems refer to Single Point of Connectivity Knowledge for HPE Storage Products (SPOCK): https://www.hpe.com/storage/spock

Product dimensions (H x W x D)

W17.5" x D26.5" x H7"

Weight

105lbs

Warranty

Warranty Standard Statement HPE Nimble Storage arrays come with the following warranties: 1-year, parts-only warranty for hardware components 90 day, software updates for defects. Additionally, HPE Nimble Storage will provide phone support for replacing a defective part. Additional support coverage is required for HPE Nimble Storage arrays. NOTE: For hardware warranty claims, defective part must be received before replacement parts are shipped.
