| Kiểu dáng |
|
| Hệ điều hành |
- Windows 10 Pro 64
- Windows 7 x86
- HP Linux-ready
- Red Hat Enterprise Linux Desktop/Workstation
|
| Bộ xử lý |
- Intel Core i5-6500 3.2Ghz Max Turbo 3.6Ghz 6MB 2133MHz 4 Cores 65W Intel vPro
- Intel Core i5-6600 3.3Ghz Max Turbo 3.9Ghz 6MB 2133MHz 4 Cores 65W Intel vPro
- Intel Xeon E3-1225v5 3.3GHz Max Turbo 3.7GHz 8MB 2133MHz 4 Cores 80W Hyper-Threading Intel vPro Intel HD Graphics P530
- Intel Xeon E3-1230v5 3.4GHz Max Turbo 3.8GHz 8MB 2133MHz 4 Cores 80W Hyper-Threading Intel vPro
- Intel Xeon E3-1240v5 3.5GHz Max Turbo 3.9GHz 8MB 2133MHz 4 Cores 80W Hyper-Threading Intel vPro
- Intel Xeon E3-1245v5 3.5GHz Max Turbo 3.9GHz 8MB 2133MHz 4 Cores 80W Hyper-Threading Intel vPro Intel HD Graphics P530 (recommend)
- Intel Xeon E3-1270v5 3.6GHz Max Turbo 4.0GHz 8MB 2133MHz 4 Cores 80W Hyper-Threading Intel vPro (recommend)
- Intel Xeon E3-1280v5 3.7GHz Max Turbo 4.0GHz 8MB 2133MHz 4 Cores 80W Hyper-Threading Intel vPro
|
| Chipset |
|
| RAM |
| Khe cắm |
|
| Loại |
- DDR4, UDIMM (Unbuffered)
- 4GB, 8GB và 16GB ECC
- 4GB, 8GB và 16GB non-ECC
|
| Tốc độ |
|
| Bộ nhớ tối đa |
|
|
| Drive Controllers |
- Integrated SATA Controller, RAID 0,1 supported: 4x 6 Gb/s ports
- Integrated RAID 0, 1 (data configuration) for PCIe SSDs
|
| Ổ đĩa cứng |
| SATA |
Lên tới (4) 3.5-inch 7200 rpm 6Gb/s drives: 500 GB, 1, 2, 3 hoặc 4 TB (16 TB max)
|
| SATA SSDs |
Lên tới (4): 128, 256, 480, 512 GB hoặc 1 TB (4 TB max)
|
| PCIe SSDs |
Lên tới (1) Z Turbo drive G2: 128, 256, 512 GB (512 GB max)
|
|
| Ổ đĩa quang |
-
HP DVD ROM Slim-Tray Drive, HP DVD RW SuperMulti Slim-Tray Drive, HP Blu-ray Writer Slim-Tray Drive, HP SD Media Card Reader
|
| Card đồ họa |
| Tích hợp |
Có sẵn theo bộ xử lý
|
| Professional 2D |
- NVIDIA NVS 310 512MB x 2
- NVIDIA NVS 315 1GB
- NVIDIA NVS 510 2GB
|
| Entry 3D |
- AMD FirePro W2100 2GB x 2
- NVIDIA Quadro K420 1GB x 2
- NVIDIA Quadro K620 2GB
|
| Mid-range 3D |
- AMD FirePro W5100 4GB
- NVIDIA Quadro K2200 4GB
|
| High-end 3D |
- AMD FirePro W7100 8GB
- NVIDIA Quadro M4000 8GB
|
|
| Âm thanh |
- Integrated Realtek HD ALC221-VB Audio
|
| Network |
- Integrated Intel I219LM PCIe GbE Controller (Intel vPro with Intel AMT 11.0)
- Intel Ethernet I210-T1 PCIe NIC
- HP X520 10GbE Dual Port Adapter
- HP 10GbE SFP+ SR Transceiver
- Intel 8260 802.11 a/b/g/n/ac with Bluetooth 4.2 PCIe NIC
|
| Cổng |
| Phía trước |
2 USB 3.0, 1 USB 2.0, 1 USB 2.0 Charging Data Port, 1 Headphone, and 1 Microphone
|
| Phía sau |
1 DVI-I Single Link and 2 DisplayPort (DP 1.2) outputs from Intel HD graphics (available on specific processors only); 4 USB 3.0 ports, 2 USB 2.0 ports, 1 serial port (optional), 1 parallel port (optional), 2 PS/2, RJ-45 (LoM), 1 Audio Line-in, and 1 Audio Line-out, Microphone; 2 IEEE 1394b ports (optional).
|
| Bên trong |
1 USB 3.0 and 3 USB 2.0 ports available as 2 separate 2x10 (3.0 x1, 2.0 x1) and 2x5 (2.0 x2) header: supports one HP Internal USB 2.0 Port Kit and one USB 3.0 Media Card Reader
|
|
| Khoang ổ đĩa |
|
| Thiết bị đầu vào |
- HP USB 1000dpi Laser Mouse
- HP USB Optical 3-Button Mouse
- HP USB Optical Mouse
- HP PS/2 Mouse
- HP 2.4GHz Wireless Keyboard & Mouse
- 3Dconnexion CADMouse
- HP USB CCID SmartCard Keyboard
- HP USB Business Slim Keyboard
- HP PS/2 Business Slim Keyboard
- HP Wireless Business Slim Keyboard
|
| Khe mở rộng |
- 1 PCIe Gen3 x16 slot
- 1 PCIe Gen3 x4 slot /x16 connector
- 1 PCIe Gen3 x1 slot/x4 connector
- 1 PCIe Gen2 x1 slot
- 1 PCI slot 32-bit (optional)
|
| Phần mềm |
HP Performance Advisor, HP Remote Graphics Software (RGS) 7.0, PDF Complete - Corporate Edition, Cyberlink PowerDVD and Power2Go, HP PC Hardware Diagnostics UEFI (Windows OS only), HP Client Security Software
|
| Bảo mật |
- HP xw4/Z2/Z4 Depth Adjustable Fixed Rail Rack Kit
- HP Solenoid Lock and Hood (SFF) Sensor
- HP Business PC Security Lock Kit
- HP UltraSlim Cable Lock Kit
|
| Kích thước |
- 39.9 x 17.0 x 44.2 cm (15.7 x 6.7 x 17.4 in)
|
| Nguồn |
- 400W 92% Efficiency wide-ranging, active Power Factor Correction (PFC)
|
| Màn hình phù hợp |
- HP DreamColor Z27x Professional Display
- HP DreamColor Z24x Professional Display
- HP Z Display Z30i 30-inch IPS Display
- HP Z Display Z27i 27-inch IPS Display
- HP Z Display Z24i 24-inch IPS Display
- HP Z Display Z23i 23-inch IPS Display
- HP Z Display Z22i 21.5-inch IPS Display
|
| Bảo hành |
|
